Lamp Power: 10W, 20W, 30W, 50W, 100W, 150W
Slim Housing Design with Good Heating Solution,
Designed for Outdoor Using, IP66
Such as Parking Area, Building, Sports Stadium, Hall, Airport
Apron, Square, etc.
Advantages:
LED replacement for HID fixtures
Energy-saving up to 80% than conventional HID systems
The luminous efficacy of light source over 135lm/w
Last 3 times longer than MHL or HID lamps
CCT range from 3000K to 6000K
Lifetime over 50,000 hours
2 years warranty
Lamps contain no lead or Mercury, ROHS compliant
Surge protection: 3KV/4KV
Suitable to use in enclosed fixtures
The led flood light housing compatible with different kinds of LED
chips and brackets--Customized products are welcomed.
Product Description:
1. Using LED light source, low light attenuation, pure light color,
etc.
2. The light source and heat sink are tightly connected,
effectively dissipating the heat and ensuring the service life of
the light source reaches 50000 hours.
3. The whole lamp adopts a unique sealed shell, which makes the
whole lamp comply with the IP66 standard.
4. Green and environmentally friendly without pollution, flexible
and convenient installation. Cold light source design, no heat
radiation, no harm to eyes and skin. Contains no pollution elements
of lead and mercury lamps, realizing true environmental protection
and energy-saving lighting.
5. Aluminum alloy shell, excellent heat dissipation performance,
effectively guarantee the service life of the LED light source.
GY3026FG Data Sheet
| Product technical parameter |
Input Voltage (V) | 220-240V AC |
| Model | GY3026FG10 | GY3026FG20 | GY3026FG30 | GY3026FG50 | GY3026FG100 | GY3026FG150 |
Power (W) | 10 | 20 | 30 | 50 | 100 | 150 |
Lighting Efficiency (lm/W) | 100lm/w |
Color Temperature (K) | 3000K-6000K |
| Power Factor | ＞0.95 |
| CRI(Ra) | ＞80 |
| LED Light Source | SMD2835 |
| IP Rate | IP66 |
| Lighting Protection Grade | 3KV | 4KV |
Lamp Dimension (mm) | 120*100*25 | 140*125*30 | 180*160*30 | 300*265*30 |
| Material | Aluminum |
| Housing Color | Grey |
| Warranty | 2 years |
