DESCRIPTION:
1. Longlife LED source
2. Energy saving
3. High Power LEDs generating cool white light
4. Pressure Die Cast Aluminum housing
5. Perfect design, Easy Installation
6. Highly Economic and reliable
7. Low maintenance
8. One-time installation
Within those world well-known LED Street Light manufacturers and
contractors in China, GYLED is a reliable supplier having a big
150w cob led street light with 3 lens projects ongoing. With
products for sale, you can wholesale LED Street Light of good
design at low cost and low price from our factory.
LED COB features:
The Chip-on-Board (COB) LED is one of the latest and most advanced
entrants to the LED market, LEDs much brighter, consume less power,
and output a higher quality beam than the older LED technologies.
LED technology is constantly being improved to improve performance,
create more use cases, and make it more versatile. Now more than
ever, LED is a more popular light source to traditional
incandescent lights, primarily because they can last a lot
longer—up to 25 times longer—and use less energy.
LED lights to come in a variety of different models and types, such
as the surface-mounted device (SMD) type or the chip-on-board (COB)
type.
COB refers to the mounting of an LED chip directly in contact with
a substrate, such as silicon carbide (SiC) or sapphire, to produce
LED arrays. COB LEDs are a newer and more advanced entrant to the
market, and they have a number of notable advantages over older LED
technologies.
Other advantages of COB LEDs include:
A highly compact, small size design;
Greater intensity, particularly at close distances;
High uniformity even when at close working distances;
A simpler single circuit design; and Superior thermal performance
for increased stability and reliability.
The mounted surface device (SMD) LED is the most common type of LED
available on the market. This type of LED is permanently fused to a
printed circuit board (PCB) and is highly popular due to its
versatility. Light bulbs, string lights, mobile phone torches, and
video game controllers are just a few examples of where SMD Les can
be found.
One of the SMD LED’s most distinct features is the number of
contacts and diodes it uses—it can have more than two contacts and
up to three diodes on a single chip, each with its own circuit with
its own anode and cathode. This can lead up to two, four, or six
contacts in a chip.
It is this configuration that makes SMDs more versatile (especially
when compared to COBs). The SMD LED can include a red, green, and
blue diode, and these can be used to create virtually any color on
the spectrum by adjusting the output level. In contrast, COB LEDs
cannot be used to create color-changing bulbs. This is because of
the single circuit design that uses only two contacts; to create
the color-changing effect, multiple channels are required.
Whilst their inability to change color means that COB LEDs have
fewer applications than SMD LEDs, they are more useful where
ultra-bright LED light is needed, such as in phone torches,
ultra-bright handheld rechargeable torches, and car headlights and
light strips.
Technical parameters:
Model No. | GY-CELL-6741LD150 | GY-CELL-6741LD200/220 |
Number of Modules | 6 | 9 |
Module Type | COB LED CHIPS |
Rated Power (W) | 150Watt | 200/220Watt |
Input Voltage(V) | AC100-240/277V/50-60Hz |
Power Factor | ≥0.95 |
Nominal Lumen Output (Lm) | ≥19500Lm | ≥28600Lm |
Luminous Efficiency (lm/w) | ≥130Lm/W |
Color Temperature (CCT) | 3000K～5700K |
CRI (Ra) | Ra70 |
Pole Connector Size (mm) | Ø48～60mm |
IP Rating | IP66 |
IK Rating | IK08 |
Working Temperature (℃) | -40～+50℃ |
Surface Finish | Anti-corrosion powder coating |
Lamp Size (mm) | 675*418*111mm |
Net Weight (Kg) | 8.4Kg | 10.4Kg |
Packing Size | 730*475*165mm |
Packing Quantity | 1 unit |
Optional Spare Parts | Photocells, Surge Protection Device, Pole Adapter |
QC
GYLED lighting company has a very strict Quality Control System,
from checking and evaluation of incoming materials to the delivery
of products, each item will be checked and tested several times.
ABOUT US
We, Shanxi Guangyu LED Lighting Co., Ltd, established in 1988, is a
professional LED lighting products manufacturer in Shanxi province
of China. Our Sales office and R&D center both are in Shanghai.
GYLED is your provider of premier quality LED lighting products and
solutions. Our main products are LED Industrial Highbay lights, LED
Flood Area lights, LED Streetlights. With our long-term great
efforts, our products comply with CE, RoHS, ERP, GS, SAA, UL, cUL,
and CCC certificates. We aim at focusing on the best products with
high quality and low cost.
Shipment
1. DHL(a big discount).
2. TNT/FedEx/UPS.
3. DHL Airway express. About 3-5days you can get them by the door
of your home or office.
4. Seaway.15-25 days. It will definitely save your shipping cost
for the large order.
FAQ
Q1 What is your terms of payment?
T/T 30% as deposit in advance, and 70% balance before the shipment,
We'll show you the photos of the products and packages before you
pay the balance.
Q2 Can I get a sample order first?
Yes.Welcome sample order to test quality.
Q3 Is your enterprise a factory or trading company?
We are a manufacturer specializing in R&D.
Q4 What kind of products are you specializing in?
We focus on the LED street light, LED flood light, LED high bay
light, LED explosive proof light, and so on.
Q5 All LED lights have a warranty?
Yes.All kinds of products at least 3 years warranty.
Q6 What about the packing for bulk orders?
If the bulk order's quantity reaches the custom MOQ, we can provide
you the customer service.
