Distribution and applies a specially designed lighting housing can
make the highbay light fixture to realize the different beam angle
for the light and to achieve the various lighting distribution
solutions of the luminaire.
| Fixture Power | Luminous Flux | Lighting Efficiency | Power Factor | Body Dimensions | Body Weight |
| 60W | 7200-10800LM | 120-150LM/W | ≥0.95 | Φ350*210mm | 4.7kg |
| 80W | 9600-12000LM | ||||
| 100W | 12000-15000LM | ||||
| 120W | 14400-18000LM | ||||
| 130W | 15600-19500LM | ||||
| 150W | 18000-22500LM |
| Item | Name | Material |
| 1 | Safety cable | Stainless steel |
| 2 | bracket | steel |
| 3 | Driver | AC driver |
| 4 | waterproof connector | steel |
| 5 | lamp body | Aluminum |
| 6 | LED module | SMD LED chips |
| 7 | Reflector | PC |
| 8 | Seal ring | Silicon |
| 9 | Lens | Glass |
| 10 | Glass Cover Ring | Aluminum |
