Main Performance and Parameters:
| Parameters Items | GY1331UV40 | GY1359UV60 |
| Rated Power | 40W | 60W |
| Input Voltage | AC220-240V 50/60 Hz |
| Power Factor | ≥0.9 |
| UV-C Light Type | Philips TUV PL-L UV-C Light |
| Peak Wavelength | 253.7 nm |
| Light Source Life | 10000H |
| Disinfection Type | Common bacteria, viruses, and other microorganisms |
Recommended Using Area Dimension | 10-15m² | 15-20m² |
| Recommended Filter Replacement Frequency | 3-6 months |
| Working Duration Limit | Available for long-term operation |
| IP Rating | IP20 |
| Electric Safety Class | CLASS I |
| Surface Treatment | Anti-corrosive powder coating |
| Dimension | 318*133*121mm | 638*133*121mm |
| Net Weight | 2.1Kg | 3.8Kg |
| Executive National Standard | GB28235；GB19258；Q/141000 GY008—2021 |
Troubleshooting:
| SN | Fault Description | Cause of Fault | Troubleshooting Method |
| 1 | The power is on, the indicator light is off, and the fan is working
normally | UV-C light is damaged | Replace with a new UV-C light |
| 2 | The power is on, the indicator light is off, and the fan does not
work | The socket has no electricity, or the product switch is faulty | Check whether the socket is electrified. If the socket has
electricity, check whether the input circuit such as the product
switch is normal |
| 3 | The fan noise has increased significantly | Too much dust on the filter | Replace with a new filter |
Commercial UV HEPA wall mount plasma ion air purifier and air
sterilizer remove order industrial uv light disinfection
sterilization lamp can help you against:
Mold Spores
Size: 10 – 30 μm
• Survives under harsh environmental conditions or dry conditions
Skin Flakes
5-10 microns
• Mattress
• Pillow
• Long-fibred carpets
• Upholstered furniture
Pollen
Size: 1 – 100 μm
• Outdoor/ Indoor plants
• From grasses, trees, flowers, and weeds
LARGE COVERAGE: Cleans spaces up to 1100 sq.ft in 50 minutes, 550
sq.ft in 25 minutes, 110 sq ft in 10 minutes. No matter in a whole
house, offices, living rooms, apartments, restaurants, or other
businesses, it performs to perfection.
EASY OPERATION: Touch control panel with 1,2,4,8hour timer, 3 fan
speeds, sleep mode, filter replacement indicator, and child lock,
great ideal for both kids and pets.
ULTRA-QUIET: Min noise level of 25dB and max of 40dB.Choose from 3
fan speeds, with the lowest setting operating virtually silent.
