Benefits
LED solar streetlight: stand-alone product, no electricity bill,
and no grid connection.
Very long lifetime: innovative high heat resistance NiMH battery &
intelligent lighting management.
Lighting service all night long: enhance personal safety, economic
and social activities.
User friendly: Plug & Play and All-in-one concept, easy
installation.
Connected product: Bluetooth enabled for product registration,
remote monitoring, troubleshooting, and lighting profile
management.
Adjusted Angle: The installation angle can be adjusted to make the
solar panels face the sun and improve the charging efficiency to the
greatest extent.
Convenient Maintenance: All components can be easily replaced.
Networking Control: Real-time monitoring of solar panels, battery,
and lampworking conditions
Overview
Lamp Power: 30W, 40W, 50W, 60W, 80W
Luminous flux: 5100~13600lm
IP66, IK09 Protection.
50000H lifetime, 5 years warranty. Innovative high heat resistance
NiMH battery & intelligent lighting management.
With Die-casting Aluminum housing, PC lens.
Streamlined design. Higher efficacy supply.
The MPPT controller is optional. Multiple optical designs, better
performance. Easy installation and maintenance.
GY4518YNLD series Solar LED street light will provide the best
lumen output, the best stability, and a very long lifetime.
User friendly: Plug & Play and All-in-one concept, easy
installation.
Connected product: Bluetooth enabled for product registration,
remote monitoring, troubleshooting, and lighting profile
management.
Heat sink
Aluminum material is with fin-type design for better heat
dissipation
Sensitive & Stable Motion Sensor
The lighting time of GYLED solar street light can last 5-6 nights
with about 60 times induction per night.
Easy Installation
GYLED solar street light can be mounted on the wall or the pole
with screws provided.
Technical Data Sheet
ITEM | GY4518YYNLD | GY4518YYNLD | GY4518YYNLD | GY4518YYNLD | GY4518TYNLD |
Nominal Power | 30W | 40W | 50W | 60W | 80W |
Solar Panel Type | Monocrystalline |
Solar Panel Parameters | 18V 40W | 18V 50W | 18V 60W | 18V 80W | 18V 100W |
Battery Type | LiFePO4 |
Battery Parameters | 12.8V 18AH | 12.8V 24AH | 12.8V 27AH | 12.8V 30AH | 12.8V 42AH |
System Voltage | 12V |
LED Brand | Lumileds |
Light Distribution | II-M, III-M |
CCT | 2200K~6500K |
Charging Time | 6Hours |
Working Time | 2-3 Days(Auto Control) |
Protection Grade | IP66/IK09 |
Luminous Efficiency | 170lm/W |
Operation | -20℃ to 60℃ |
Net Weight(kg) | 11.3 | 13 | 14.5 | 15.5 | 18 |
Gross Weight(kg) | 13.3 | 15 | 16.5 | 19.5 | 23.5 |
Package Dimensions(mm) | 830*455*180 | 975*455*180 | 1083*455*180 | 1447*455*180 | 1577*455*180 |
Material | Aluminum |
Luminous Flux | 5100lm | 6800lm | 8500lm | 10000lm | 13600lm |
Warranty | 5 Years |
Advantages:
Easy Installation, Low Maintenance,
High efficiency and energy saving.
All in one solar-led street light is raised led light sources which
are powered by solar panels generally mounted on the lighting
structure or integrated into the pole itself. The solar panels
charge a rechargeable battery, which powers a led lamp during the
night. Most solar lights turn on and turn off automatically by
sensing outdoor light using solar panel voltage. Solar streetlights
are designed to work throughout the night. Many can stay lit for
more than one night if the sun is not in the sky for an extended
period of time.
Adjusted angle: The installation angle can be adjusted to make the
solar panels face the sun and improve the charging efficiency to the
greatest extent.
Convenient maintenance: All components can be easily replaced.
