5 years warranty led panel highbay lights 100w 200w 300w warehouse
lighting
GYLED LED Lights Warranty:
We do the warranty not from guarantee words or paper, but from our
quality confidence and responsibility to our customers
-----(1) If the driver failed, we'll send a new driver.
-----(2) If the LED failed, we'll send a new LED.
-----(3) Unclear reason, we'll send full new set.
Product Features:
APPLICATION
— Ideal one-for-one replacement of conventional lighting systems
such as HID and fluorescent. Applications include manufacturing,
warehousing, gymnasiums, light industrial spaces, office,
classroom, retail space, parking structure, and other large indoor
spaces with mounting heights ranging from 15m – 40m.
1. COST SAVING
— Easy installation can save much more time and labor cost and it
can provide virtually maintenance-free service.
— LED light engines and drivers are fields replaceable.
2. ELECTRICAL
— 90% lumen maintenance at 50,000 hours; predicted life of more
than 100,000 hours. Thermally protected driver standard with 0-10V
dimming. 4KV surge protection standard
3. OPTICS
— Light distribution to meet both horizontal and vertical light
level requirements. Reflectors are precision formed and painted a
high reflectance white. A Semi-diffuse lens is standard to provide
glare control and LED protection.
4. LISTINGS
— ETL certified to US and Canadian safety standards. Listed by ETL
to meet UL 1598 standards for damp location and -20°C to 40°C
ambient. Ambient operating temperatures vary referring to end-user
environment and application. — Components are RoHS compliant.
NEW DESIGNED LED LINER GHBAY LIGHTS
This highbay light is a new generation of eco-friendly luminaire
offering maximum light output, exceptional illumination, and energy
savings. This new LED luminaire gives budget-conscious customers a
reliable LED high bay solution. In addition to its low initial
cost, the fixture saves up to 60% in energy costs over HID and
costs less to operate than popular fluorescent products —not to
mention the maintenance savings.
Characteristic
1. 1*2FT
Model | GY-LHB12F65P | GY-LHB12F80P | GY-LHB12F100P |
Power(watt) | LED 65W | LED 80W | LED 100W |
LPW | 9000LM | 10800lm | 13500lm |
Typical Lumen | 135LM/W |
CCT | 4000K/5000K/5700K |
Certification | ETL&cETL/Premium DLC4.1 HighBay/LM90@54000 hours |
CRI | >Ra80 |
Size | 1*2FT |
Comparable Light Source | 2-lamp T5HO, 4-lamp T8,
| 2-lamp T5HO, 4-lamp T8, 250W HID | 4-lamp T5HO, 6-lamp T8, 4-lamp T8, 250W HID |
2. 1*4FT
Model | GY-LHB14F165P |
Power(watt) | LED 165W |
LPW | 22000LM |
Typical Lumen | 135LM/W |
CCT | 4000K/5000K/5700K |
Certification | ETL&cETL/Premium DLC4.1 HighBay/LM90@54000 hours |
CRI | >Ra80 |
Size | 1*4FT |
Comparable Light Source | 4-lamp T5HO, 6-lampT8, 400W HID, 6-lamp T5HO, 8-lamp T8 |
3. 2*2FT
Model | GY-LHB22F200P |
Power(watt) | LED 200W |
LPW | 27000LM |
Typical Lumen | 135LM/W |
CCT | 4000K/5000K/5700K |
Certification | ETL&cETL/Premium DLC4.1 HighBay/LM90@54000 hours |
CRI | >Ra80 |
Size | 2*2FT |
Comparable Light Source | 6-lamp T5HO, 8-lamp T5HO, 8-lamp T8, 750/800W |
4. 2*4FT
Model | GY-LHB24F320P |
Power(watt) | LED 320W |
LPW | 43200LM |
Typical Lumen | 135LM/W |
CCT | 4000K/5000K/5700K |
Certification | ETL&cETL/Premium DLC4.1 HighBay/LM90@54000 hours |
CRI | >Ra80 |
Size | 2*4FT |
Comparable Light Source | 10-lamp T5HO, 750W HID |
Certificates
After several years of endeavor and development, concentrating on
the innovative spirit, GYLED established a professional management
team. The company is guided and operated according to requirements
from management systems of ISO9000, ISO14001 and OHSAS18001, and
with introducing ERP IMS (Information Management System),
management decision becomes more scientific and efficient. We will
also continuously optimize the management system, provide an
excellent platform, and ensure our every employee to create value
for users.
Professional Packaging
• Foam Protection to Withstand Harsh Transportation and Impact
• Carton and Pallet with Foam and Cling Wrap to Withstand Impact,
High Humidity in Containers, and Rainy Weather
• To Guarantee an Intact Condition when Receiving the Goods.
ABOUT US
We, Shanxi Guangyu LED Lighting Co., Ltd, established in 1988, is a
professional LED lighting products manufacturer in Shanxi province
of China. Our Sales office and R&D center both are in Shanghai.
GYLED is your provider of premier quality LED lighting products and
solutions. Our main products are LED Industrial Highbay lights, LED
Flood Area lights, LED Streetlights. With our long-term great
efforts, our products comply with CE, RoHS, ERP, GS, SAA, UL, cUL,
and CCC certificates. We aim at focusing on the best products with
high quality and low cost.
Shipment
1. DHL(a big discount).
2. TNT/FedEx/UPS.
3. DHL Airway express. About 3-5days you can get them by the door
of your home or office.
4. Seaway.15-25 days. It will definitely save your shipping cost
for the large order.
FAQ
Q1 What is your terms of payment?
T/T 30% as deposit in advance, and 70% balance before the shipment,
We'll show you the photos of the products and packages before you
pay the balance.
Q2 Can I get a sample order first?
Yes.Welcome sample order to test quality.
Q3 Is your enterprise a factory or trading company?
We are a manufacturer specializing in R&D.
Q4 What kind of products are you specializing in?
We focus on the LED street light, LED flood light, LED high bay
light, LED explosive proof light, and so on.
Q5 All LED lights have a warranty?
Yes.All kinds of products at least 3~5 years warranty.
Q6 What about the packing for bulk orders?
If the bulk order's quantity reaches the custom MOQ, we can provide
you the customer service.
